ZnSe Plano-Convex Infrared Lens

  • Product Item : RT20210419027#
  • Category:
  • Substrate:ZnSe
  • Diameters:12.7mm-25.4mm,or custom
  • Coating:10.6um antireflective coating.
  • Unit Price:50USD-500USD per pcs
  • Product description:ZnSe Plano-Convex Lens, ZnSe Plano-Convex IR Lens, ZnSe IR Lens,Zinc selenide plano convex lens, Zinc selenide lens, Zinc selenide infared lens, Zinc selenide lens, Zinc selenide convex lens, Znse con
  • INQUIRY



General Introduction: Raytek zinc selenide is an excellent choice for infrared lens materials, suitable for wavelength between 600 nm and 16 um. Its low absorption coefficient makes it an ideal choice for applications / instruments using CO2 lasers. In the middle infrared region, GVD is very low, which makes it very suitable for the application of femtosecond infrared pulse.

Products Name: ZnSe Plano-Convex Infrared Lens

Alias: ZnSe Plano-Convex Infrared Lens, ZnSe Infrared Lens, ZnSe Plano-Convex Lens, ZnSe Plano-Convex IR Lens, ZnSe IR Lens,Zinc selenide plano convex lens, Zinc selenide lens, Zinc selenide infared lens, Zinc selenide lens, Zinc selenide convex lens, Znse convex lens,etc

Lens Substrates:

ZnSe(zinc selenide)

Optional I:

ZnSe(zinc selenide)

from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC

Optional II:

Equivalent ZnSe(zinc selenide)

Made in China, C-laser own brands

AR. Coating:

10.6um antireflective coating.

Main Applying:

Applying Fields I:

Femtosecond infrared pulse

CO2 laser

Applying Fields II:

Focus, collect and collimate light

Focusing and collimating laser beam

Collimating the optical fiber output

Appling Fields III:

Other

Products Highlights:

1).High infrared transmittance ZnSe substrate

2).Planoconvex lens shape for focusing applications

3).10.6 um antireflective coating

4).Standard focal length suitable for various lens sizes

5).Different grades materials for option.

6).High precision & high surface roughness;

7).Sizes can be customized as per the customers’ request

8).Quick lead time and delivery time.

9).Matching super optics custom and processing capacity, including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.

10).Excellent post-sale quality warranty, with “3R”-return, replace & refund policy

Main Optical Tech Specification:

Lens Shape

Plano-Convex

Surface Accuracy

Irregularity

-

Lens Material

ZnSe

Surface Accuracy, Power

-

Antireflection Coating

R<0.75% at 10.6 µm

Chamfers

-

Coating Type

-

Chamfers Angle/Tolerance

-

Coating Code

-

Focal Length

Tolerance

-

Damage Threshold

-

Centration

3 arc min

Surface Quality

40-20 scratch-dig

Clear Aperture

≥central 90% of

diameter

Surface Flatness

-

OEM/ODM

Accepted

Main Physical Size Specification:

Products Code

Diameters

EFL

AR.film Wavelength

RT01031501

12.7mm

25.4mm

600-16000nm

RT01031502

25.4mm

50mm

600-16000nm

RT01031503

25.4mm

75mm

600-16000nm

RT01031504

25.4mm

100mm

600-16000nm

RT01031505

25.4mm

150mm

600-16000nm

RT01031506

25.4mm

200mm

600-16000nm

RT01031507

25.4mm

250mm

600-16000nm

RT01031508

25.4mm

500mm

600-16000nm

RT01031509

25.4mm

1000mm

600-16000nm

Custom

Custom

Custom

Main Cooperation Materials Manufacturers:

CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC

Main Export Countries & Areas:

Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.

Raytekoptics Extra value added services offered:

1). Optical workcraft & process solution design;

2). Rough processing raw materials;

3). Semi finishing raw materials;

4). Fabricate custom sizes and shapes;

5). Design and supply custom coatings;

6). Modify and resurface customer supplied materials;

7). Drill holes, notch glass and provide beveled substrates;

8). Precision polish optics with non-standard aspect ratios;

Payment Method: by T/T or Western Union.

Delivery time: 7-10 days.

Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products with “3R” policy. For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
