General Introduction:
From prototype to high-volume production Raytek Optics is dedicated to manufacturing custom plano optics to meet your precise specifications. Since 2017, Raytek Optics has built a worldwide reputation in custom optics manufacturing pairing traditional craftsmanship with leading-edge technology. Our 50,000 sq. ft. facility houses the larger collection of cnc cutting machines,cnc milling machine centers, double-sided polishing machines,PIB polishing machine, MRF polishing machines, etc in Shanghai,China.
Custom Manufacturing Capacity 1: Ultra big size CNC waterjet cutting
Water jet cutting technology, which takes water as a cutter, is originally called high-pressure water jet cutting technology. This technology originated in the United States. Used in aerospace military industry. Because the cold cutting will not change the physical and chemical properties of materials, it is popular. After continuous improvement of the technology, pomegranate sand was mixed in high-pressure water, which greatly improved the cutting speed and thickness of the water knife. Now water jet has been widely used in optical glass production line.
With ultra-precise & superhigh-pressure cnc waterjet cutting equipment, Raytek Optics can provide waterjet cutting solutions for big or super big size optical materials into different small sizes
Main Processing Technical Capacity Data:
Items Value
Max. Cutting Size Range: 2000mm*2000mm
Waterjet Cutting Nozzles Size 0.004 to 0.010 inches
Water Jet Pressure & Speed 40kpsi: Mach 2, twice the speed of sound
60kpsi: Mach 3, Three times the speed of sound
Max. Cutting Thickness No limits
Standard Cutting Accuracy 0.1mm

Raytek Waterjet Cutting Speed & Processing Efficiency:
Cutting Pressure & Power 270Mpa(40Kpsi) 30HP 380Mpa(55Kpsi) 50HP
Water Flow 2.2L/min(0.50GAI/min) 3.2L/min(0.73GAL/min)
Grinding Materials Consumption 0.4KG/min(0.9lb/min) 0.6KG/min(1.4lb/min)

Thickness Cutting Speed(mm/min) Cutting Speed(mm/min)
Optical glass 2.5mm 3900 4400
Optical glass 6.0mm 1200 1600
Optical glass 20mm 300 400
Optical glass 50mm 120 140

Main Cutting Technologies Characters:
1).The water jet belongs to the cold cutting process, which will not generate heat in the cutting process, so it will not make the glass deformed and discolored due to the heat in the cutting process
2).The cutting gap of the water knife is very small, about 1 mm. The cutting surface is smooth and smooth, and there is no need for secondary processing.
3).The cutting ability of the water knife is very strong. When cutting with pomegranate sand, the thickness of glass can be cut up to 200 mm
4).For the plane processing, the composition ability of the water jet is very good, you can cut out any graphics you want
5).In the process of water jet cutting, the force of water jet is compressed to about 1 mm, which will not have too much impact on the cutting material
6).When using water knife to cut, the installation of the workpiece is very simple, just need to place the cutting workpiece on the cutting platform, do not need too much cumbersome fixed.
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:

Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.

Raytekoptics Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
Quality Warranty: Ruitaiphotoelectric(Raytekoptics) offers quality warranty for our optics products & OEM & ODM service with "3R" policy--return, replace & refund policy.
For any inferior-quality products, Ruitaiphotoelectric(Raytekoptics) is responsible for return, replacement and refund.
